Houston Plating & Coatings (HP&C) has added high temperature heat treatment of electroless nickel plating to its broad line of corrosion and wear protection services.
BeforeHigh phosphorus electroless nickel is widely used in applications due to its functional properties such as hardness, wear resistance and corrosion protection. Applying a well-defined method of thermal treatment to the electroless nickel plated steel substrate at temperatures above 600˚C further enhances these properties by forming a highly protective, thick, greenish oxide film and an interdiffusion layer with the substrate.
William Howard, CEO of HP&C, says “the benefits of this high heat treatment are substantial and include increased corrosion protection, hardness, deposit adhesion, deposit passivity, and resistance to abrasion. These are especially valuable for plated parts that will be in service in extremely corrosive environments”.
AfterAccording to Eric Turner, COO and head of QC for HP&C, “this process generates three distinct barrier layers of protection that produce a significant improvement by the formation of a nickel oxide layer, a nickel phosphorus rich layer and a nickel-iron diffusion layer which is continuous and ductile.”
The first interdiffusion layer occurs between the steel substrate and the deposited nickel metal forming a Ni-Fe alpha phase. As this diffusion occurs, at temperatures above 550˚C, phosphorus migrates through the deposit toward the surface resulting in a Ni-P3 layer with larger nickel clusters forming a barrier to corrosion. The third outermost layer forms and consists of a nickel oxide layer.
Already employing the largest nickel plating tanks in the Southwest, and cited as one of the best nickel plating shops in the country by Products Finishing magazine surveys, HP&C continues to add new capabilities and services for its clients from across the country, as well as Canada and Mexico. With a focus on serving the energy industry, the company has expanded to serve additional industries, including waste water treatment, and industrial gas.
Learn more at www.houstonplating.com or call 800.946.0172
